The battery system utilizes high security LFP batteries, ideal for home use, and can be connected to solar and wind energy systems.
Supports no-dialing code design.
Supports WIFI function for online diagnosis and OTA upgrade.
Long cycle life up to 6000 times.
Equipped with specialized intelligent BMS, which can effectively prevent overheating and over-discharge, over-charge and short circuit.
Model | A11-010KCAA |
Nominal Voltage | 51.2V(16S) |
Nominal Capacity | 200Ah |
Nominal Energy | 1024Wh |
Internal Resistance (AC) | ≤40mΩ |
| Designed Life | ≥10 years |
Recommended Charging Voltage | 56.0V±0.5V |
Maximum Operating Current | 100A |
Discharge Cut-off Voltage | 48V±0.2V |
Charging Temperature Range | 0℃~50℃ |
Discharge Temperature Range | -20℃~55℃ |
Storage Temperature Range | -20℃~45℃ @ 60%±25% relative humidity |
Dimensions (L*W*Hmm) | 762*520*148 |
Weight | 85kg |
Communication Mode | RS232-PC,RS485(B)-PC RS485(A)-Inverter,Canbus-Inverter |
Number of Parallel Connections | Supports up to 16 units in parallel (6 batteries in parallel recommended) |
Certification | UN38.3,MSDS,UL1973(Cell),IEC62619(Cell) |
Ultra-thin design
IP65 protection
Dial-free parallel connection of units
WIFI upgrade function reserved
